Paslanmaz Çelik Profil | Özsan Paslanmaz Metal

Dış Kutur (mm)	KARE PROFİLLER
	KARE PROFİLLER
	1,0	1,2	1,5	2,0	2,5	3,0	4,0	5,0	6,0


10 x 10	0,294
12 x 12	0,358	0,415	0,508
15 x 15	0,453	0,538	0,661
16 x 16	0,485	0,576	0,709	0,920
20 x 20	0,613	0,729	0,900	1,175
25 x 25	0,772	0,921	1,140	1,494	1,846	2,179
30 x 30	0,932	1,112	1,379	1,813	2,222	2,645
35 x 35	1,091	1,303	1,618	2,132	2,629	3,118
40 x 40	1,251	1,495	1,857	2,451	3,036	3,602	4,708
45 x 45	1,410	1,686	2,097	2,770	3,433	4,081	5,309
50 x 50	1,570	1,878	2,336	3,089	3,818	4,559	5,960
60 x 60			2,814	3,727	4,607	5,516	7,222
70 x 70			3,293	4,365	5,408	6,473	8,504
80 x 80			3,771	5,003	6,203	7,430	9,807	12,095
100 x 100			4,728	6,279	7,918	9,343	12,358	15,322	18,236
120 x 120				7,555		11,257	14,910	18,512	22,064
150 x 150				9,469		14,129	18,738	23,297	27,806

Dış Kutur (mm)	DİKDÖRTGEN PROFİLLER
	DİKDÖRTGEN PROFİLLER
	1,0	1,2	1,5	2,0	2,5	3,0	4,0	5,0	6,0
	1,0	1,2	1,5	2,0	2,5	3,0	4,0	5,0	6,0
20 x 10	0,453	0,538	0,661
20 x 15	0,533	0,634	0,781
25 x 15	0,613	0,729	0,900	1,175
30 x 10	0,613	0,729	0,900
30 x 15	0,693	0,825	1,020	1,335
30 x 20	0,772	0,921	1,140	1,494
35 x 20	0,852	1,017	1,259	1,654
40 x 15	0,852	1,017	1,259	1,654
40 x 20	0,932	1,112	1,379	1,813
40 x 30	1,091	1,303	1,618	2,132	2,661	3,156
50 x 20	1,091	1,303	1,618	2,132
50 x 25		1,399	1,738	2,292
50 x 30	1,251	1,495	1,857	2,451
50 x 40		1,686	2,097	2,770	3,433	4,081
60 x 20		1,495	1,857	2,451
60 x 30		1,686	2,097	2,770	3,412	4,081
60 x 40		1,878	2,336	3,089	3,819	4,559	5,960
80 x 40		2,261	2,814	3,727	4,600	5,516	7,222
80 x 60			3,293	4,365	5,408	6,473	8,504
100 x 40			3,293	4,365	5,408	6,473	8,504
100 x 50			3,532	4,684	5,790	6,952	9,115	11,268
100 x 60			3,771	5,003		7,430	9,807	12,095
100 x 80				5,642		8,387	11,083	13,728	16,324
120 x 40				5,003		7,430	9,807
120 x 60				5,642		8,387	11,083	13,728	16,324
120 x 80				6,279		9,343	12,358	15,322	18,236
150 x 50				6,279		9,343	12,358	15,322	18,236
200 x 100				9,469		14,129	18,738	23,297	27,806
